(2011-2014) 5.0L Ford F-150 Supercharger ROUSH R2300 Phase 2 Kit - 570 HP



NOTE: 2014 F-150 Only requires the use of a Supercharger Supplemental FEAD Kit #421821. Please add from the drop down menu if you have a 2014.

This F-150 Supercharger Kit by ROUSH¨ delivers 570 HP and 530 LB/FT of torque to the 2011-2014 Ford F-150 5.0L-4v V8 powertrain.

The ROUSH 2011-2014 5.0L F-150 Phase 2 Calibrated Supercharger Kit is part of the TVS (Twin Vortices Series) line of superchargers developed by ROUSH that have raised the bar for performance and reliability. This is the same line that has been used and proven for years in ROUSH-built vehicles.

The ROUSH R2300 supercharger features Eaton's new cutting edge Twin Vortices Series technology (TVS) rotating assembly that delivers more power and better fuel economy in a smaller package for uncompromising performance.

The ROUSH R2300 TVS supercharger is a roots-type, positive displacement supercharger that features twin four-lobe rotors that are twisted 160-degrees.

By comparison, the original Eaton supercharger rotating assembly featured three lobes twisted 60 degrees. The fourth lobe and added twist, when combined with NEWLY redesigned air inlet and outlet ports, greatly enhance thermal efficiency, deliver higher volumetric capacity, enable higher operating speeds, creates a smoother, more efficient flow of air into the engine and has improved noise and vibration characteristics.

Unlike turbo-charging and centrifugal superchargers, the ROUSH R2300 TVS supercharger provides instant throttle response and can generate increased power through the engine's entire powerband.

The supercharger design runs on the first-sheave FEAD allowing ROUSH to integrate a heavy duty tensioner designed to handle the increased load of the R2300 supercharger and applying the load closer to the #1 main bearing, thus increasing durability.

 The primary components of this ROUSH R2300 TVS Supercharger Kit include:

 -ROUSH R2300 2.3L TVS Supercharger
 -Fuel charging assembly with ROUSH designed upper and lower aluminum intake manifolds
 -Twin 60mm throttle body and matching throttle body spacer
 -High-flow cold air induction system featuring an injection molded air box, blow-molding clean air tube and high flow, washable, premium air filter
 -Large 100mm MAF (Mass Air Flow) tube
 -High efficiency intercooler system featuring dual-core low temp radiator, degas bottle, high capacity air-to-water intercooler and formed hoses with abrasion-resistant sleeves
 -1st sheave FEAD system with heavy duty tensioner for greater durability
 -Unique high flow fuel rail with 47lb injectors
 -Zero heat range spark plugs
 -All required fasteners, wiring, brackets, hoses and clamps
 -ROUSH custom PCM calibration


This kit is protected by an extended parts warranty (ROUSH Supplied Parts Only), which is for 3 years or 36,000 miles from retail purchase date. Please contact ROUSH customer service for more information at 1-800-59-ROUSH.

Highlights:

-Produces 570 horsepower and 530 lb-ft of torque (210hp and 150lb-ft gain over stock)
 -R2300 Supercharger featuring Eaton's new TVS Technology. The new Twin Vortices Series features four-lobe rotors with high-flow inlet and outlet ports that greatly enhance thermal efficiency, enabling greater   volumetric capacity at higher revolutions per minute (RPM)

 -Fuel charging assembly with ROUSH designed upper and lower aluminum intake manifolds
 -High efficiency intercooler system featuring dual-core low temp radiator, degas bottle, high capacity air-to-water intercooler and formed hoses with abrasion-resistant sleeves
 -Twin 60mm throttle body and throttle body spacer
 -ROUSH cold air induction system featuring an injection-molded air box, blow-molded clean air tube and high flow, washable, premium air filter
 -100mm MAF (Mass Air Flow) tube/housing
 -1st sheave FEAD system with heavy duty tensioner for increased durability and less parasitic loss
 -80mm pulley
 -2011-2014 Ford F-150 5.0L-4v engine
 -3 Year/36,000 Mile Parts warranty included (ROUSH Supplied Parts Only)
 -NOT approved for sale or installation in the state of California
 -Part # 421435
